High Productivity Motor Vehicle Permit Application
Permit Information
Reference No.:  170302413
Road Network:  Both
Application Type:  New
Existing Permit #:
Permit Type: Higher Mass
Pro-forma: Pro-forma
General Information
Company Name: Fulton Hogan - Auckland
TSL Number: 05457
Contact Person: Brett Horrobin
Depot Location: Reliable Way, Mt Wellington
Postal Address: Private Bag 11-900 Ellerslie
Postal Code:
Applicant Email:
Date of Application: 02/03/2017
Date Permit Required: 16/03/2017
Tel No.:
Cellphone No.:
Permit From date :
Permit To date:
Route From: 350 McNicol Road, Clevedon
Route To: 40 Leon Leicester Avenue, Mt Wellington
Route From Postal Code: 2585
Route To Postal Code: 1060
Return Trip: Yes
Route Description: Head northwest on McNicol Rd toward Quinns Rd then turn left onto Tourist Rd. Turn left onto Papakura-Clevedon Rd.
Head southwest on Papakura-Clevedon Rd toward Burnside Rd then turn right onto Mullins Rd. Turn left onto Airfield Rd. Head west on
Airfield Rd then at the roundabout, take the 3rd exit onto Mill Rd. At the roundabout, take the 1st exit onto Alfriston Rd/Pacific Coast Hwy.
Continue to follow Pacific Coast Hwy. At the roundabout, take the 1st exit onto Hill Rd/Pacific Coast Hwy. Turn right onto Grande Vue
Rd/Pacific Coast Hwy then slight right to stay on Grande Vue Rd/Pacific Coast Hwy. Merge onto State Highway 1. Take exit 438 for Urban
Route 6/Mount Wellington Hwy. Turn right onto Mount Wellington Hwy/Urban Route 6. Turn left onto Penrose Rd then head west on Penrose
Rd toward Ruawai Rd. Turn right onto Leonard Rd and continue straight onto Leon Leicester Ave where the destination is on the right.
Comments ( e.g. Previous related permit number, etc ):
Vehicle Information
Vehicle Type: R22T23
# Units: 2
Total Width (m): 2.50
Total Height (m): 3.00
Total Length (m): 22.70
Width to Outside Tyres (m): 2.50
Load Description: Aggregates
Total Mass Applied For (kg): 57800.00
Load: Divisible
Axle Weight flexibility (AWF): Yes
AWF limits: HPMV
Unit Reg. JAY191
Reg. Number: JAY191
GVM (kg): 27000.00
GCM (kg): 58000.00
Total Unit Mass (kg): 27000.00
No. Of Axles: 4
Is Prime Mover: Yes

Axle information for unit JAY191
Steering
Track
Max Mass (user  Spacing from
Axle Set
Axle Type
Tyre Size
Suspension Type
Mass (kg)
Axle
Outer
defined kg)
prev (m)
(TS) Twin
(S) Single
Yes
275/70/22.5
(L) Leaf Spring
2.09
5400.00
0.00
Steer
Tyred Axle
(TS) Twin
(S) Single
Yes
275/70/22.5
(L) Leaf Spring
2.09
5400.00
2.05
Steer
Tyred Axle
(T) Twin
(AD) Air Bag - Drive
No
(T) Tandem
275/70/22.5
1.85
8000.00
3.26
Tyred Axle
Axle
(T) Twin
(AD) Air Bag - Drive
No
(T) Tandem
275/70/22.5
1.85
8000.00
1.37
Tyred Axle
Axle
Unit Reg. 1U754
Reg. Number: 1U754
GVM (kg): 32000.00
GCM (kg): 58000.00
Total Unit Mass (kg): 32000.00
No. Of Axles: 5
Is Prime Mover: No
Axle information for unit 1U754
Track
Max Mass (user
Spacing from
Steering Axle Axle Set
Axle Type
Tyre Size
Suspension Type
Mass (kg)
Outer
defined kg)
prev (m)
(T) Twin
265/70
No
(T) Tandem
(A) Air Bag
1.88
6200.00
6.63
Tyred Axle
R19.5
(T) Twin
265/70
No
(T) Tandem
(A) Air Bag
1.88
6200.00
1.31
Tyred Axle
R19.5
(T) Twin
265/70
No
(Tri) Tri-axle
(A) Air Bag
1.88
6200.00
3.18
Tyred Axle
R19.5
(T) Twin
265/70
No
(Tri) Tri-axle
(A) Air Bag
1.88
6200.00
1.26
Tyred Axle
R19.5
(T) Twin
265/70
No
(Tri) Tri-axle
(A) Air Bag
1.88
6200.00
1.27
Tyred Axle
R19.5

Permit : Summary | OPermit
Page 1 of 2
OPermit
Appl. No. 82592
Company  Fulton Hogan C/O Transport Specifications Ltd
Name:
BESS No.:
Region: Auckland
Contact
Jared Dodds
Email:
Person:
Phone
Fax
09 4159085
Number:
Number:
Depot
Mobile
Penrose
Location:
Number:
Comment: SAP Business Partner: 101005093
Postal
PO BOX 302 852 North Harbour 0751
Address: Auckland
Application Type: HPMV
Permit Type:
HPMV - Higher Mass
Load Type:
Divisible
Feasibility Study: Yes
Permit From:
17/03/2017
Permit To:
17/03/2019
HVI No.:
JAY191+1U754*
Registration Nos:
JAY191
Vehicle Type:
HPMV
1U754
Gross Combined Mass from
58000
Max Speed:
90 (km/h)
COL:
Overall Dimensions (m)
Width:
2.5
Height:
3.0
Length:
22.7
Load Description:
Aggregates
Axle Weight Flexibility:
None
Vehicle Design:
R22T23
Axle
Track
Track
Axle Position: Type:
Tyre Size: Suspn:
Weight: Spacing: Axle Index:
Set:
(Out):
(In):
1
S
TS
Standard
L
2.09
5.5
0.0
1.06
2
S
TS
Standard
L
2.09
5.5
2.05
1.06
3
T
T
Standard
AD
1.85
8.2
3.26
1.11
4
T
T
Standard
AD
1.85
8.2
1.37
1.11
5
T
T
Standard
A
1.88
8.2
6.63
1.11
6
T
T
Standard
A
1.88
8.2
1.31
1.11
7
T
TRI
Standard
A
1.88
7.0
3.18
1.11
8
T
TRI
Standard
A
1.88
7.0
1.26
1.11
9
T
TRI
Standard
A
1.88
7.0
1.27
1.11
Vehicle Parameters - GM: 64.80 VAI: 1.11 VGI: 1.58 Crit. WB: 20.33
http://opermit.nzta.govt.nz:8080/OPermit/app/main.htm?_flowExecutionKey=_cA4A9...
3/03/2017

Permit : Summary | OPermit
Page 2 of 2
Route Name:
McNicol Road to Leon Leicester Ave
Region: Auckland
Route Description: HPMV 29/07/16 Return Via Reverse Route (9 Axle Unit Only)
[Group 1: Contains 1 section]
Highway:
From
Junc:
Ref-Stn:
Disp:
To Junc:
Ref-Stn:
Disp:
SH1N
448
2.907
431
7.92
Route Section Comment: McNicol Rd (AT) - Tourist Rd (AT) - Papakura / Clevedon Rd
(AT) - Mullins Rd (AT) - Airfield RD (AT) - Mill Rd (AT) -
Alfriston Rd (AT) - Straford Rd (AT) - Hill Rd - Grande Vue Rd
(AT) - SH1N - Exit 438 (Mt Wellington Northbound Off Ramp
Exit 438)
Misc. Bridges
HILL ROAD UNDERPASS (OVER SH1N)
[Group 2: Contains 1 section]
Highway:
From
Junc:
Ref-Stn: Disp: To Junc:
Ref-Stn: Disp:
EXIT438NB
EXIT438NB0
EXIT438NB9
Route Section Comment: Mt Wellington Highway Northbound Off Ramp
Misc. Bridges
[Group 3: Contains 1 section]
Highway:
From
Junc:
Ref-Stn: Disp: To Junc:
Ref-Stn: Disp:
EXIT438SB
EXIT438SB0
EXIT438SB9
Route Section Comment: Mt Wellington Highway Southbound Off Ramp
Misc. Bridges
[Group 4: Contains 1 section]
Highway:
From
Junc:
Ref-Stn:
Disp:
To Junc:
Ref-Stn:
Disp:
OB2B
2B0
2B9
Route Section Comment: Mt Wellington Highway (AT) - Penrose Road (OB2B) -
Leonard Road (AT) - Leon Leicester Ave (AT)
Misc. Bridges
http://opermit.nzta.govt.nz:8080/OPermit/app/main.htm?_flowExecutionKey=_cA4A9...
3/03/2017
