High Productivity Motor Vehicle Permit Application
Permit Information
Reference No.: 160726130
Road Network: Both
Application Type: New
Existing Permit #:
Permit Type: Higher Mass
Pro-forma: Pro-forma
General Information
Company Name: Fulton Hogan Ltd - Auckland
TSL Number: 05457
Contact Person: Brett Horrobin
Depot Location: Reliable Way, Mt Wellington
Postal Address: Private Bag 11-900 Ellerslie
Postal Code:
Applicant Email: [email address]
Date of Application: 26/07/2016
Date Permit Required: 15/08/2016
Tel No.: 09 5807160
Cellphone No.: 0274748602
Permit From date : 15/08/2016
Permit To date: 15/08/2018
Route From: 350 McNicol Road Clevedon
Route To: 40 Leon Leicester Avenue Mt Wellington
Route From Postal Code: 2585
Route To Postal Code: 1060
Return Trip: Yes
Route Description: Head northwest on McNicol Rd toward Quinns Rd then turn left onto Tourist Rd. Turn left onto Papakura-Clevedon Rd.
Head southwest on Papakura-Clevedon Rd toward Burnside Rd then turn right onto Mullins Rd. Turn left onto Airfield Rd. Head west on
Airfield Rd then at the roundabout, take the 3rd exit onto Mill Rd. At the roundabout, take the 1st exit onto Alfriston Rd/Pacific Coast Hwy.
Continue to follow Pacific Coast Hwy. At the roundabout, take the 1st exit onto Hill Rd/Pacific Coast Hwy. Turn right onto Grande Vue
Rd/Pacific Coast Hwy then slight right to stay on Grande Vue Rd/Pacific Coast Hwy. Merge onto State Highway 1. Take exit 438 for Urban
Route 6/Mount Wellington Hwy. Turn right onto Mount Wellington Hwy/Urban Route 6. Turn left onto Penrose Rd then head west on Penrose
Rd toward Ruawai Rd. Turn right onto Leonard Rd and continue straight onto Leon Leicester Ave where the destination is on the right.
Comments ( e.g. Previous related permit number, etc ):
Vehicle Information
Vehicle Type: R22T23
# Units: 2
Total Width (m): 2.50
Total Height (m): 3.00
Total Length (m): 22.70
Width to Outside Tyres (m): 2.50
Load Description: Aggregates
Total Mass Applied For (kg): 57800.00
Load: Divisible
Axle Weight flexibility (AWF): Yes
AWF limits: HPMV
Unit Reg. JAY191
Reg. Number: JAY191
GVM (kg): 27000.00
GCM (kg): 58000.00
Total Unit Mass (kg): 27000.00
No. Of Axles: 4
Is Prime Mover: Yes
Axle information for unit JAY191
Steering
Track
Max Mass (user Spacing from
Axle Set
Axle Type
Tyre Size
Suspension Type
Mass (kg)
Axle
Outer
defined kg)
prev (m)
(TS) Twin
(S) Single
Yes
275/70/22.5
(L) Leaf Spring
2.09
6300.00
0.00
Steer
Tyred Axle
(TS) Twin
(S) Single
Yes
275/70/22.5
(L) Leaf Spring
2.09
6300.00
2.05
Steer
Tyred Axle
(T) Twin
(AD) Air Bag - Drive
No
(T) Tandem
275/70/22.5
1.85
9050.00
3.26
Tyred Axle
Axle
(T) Twin
(AD) Air Bag - Drive
No
(T) Tandem
275/70/22.5
1.85
9050.00
1.37
Tyred Axle
Axle
Unit Reg. 1U754
Reg. Number: 1U754
GVM (kg): 32000.00
GCM (kg): 58000.00
Total Unit Mass (kg): 32000.00
No. Of Axles: 5
Is Prime Mover: No
Axle information for unit 1U754
Track
Max Mass (user
Spacing from
Steering Axle Axle Set
Axle Type
Tyre Size
Suspension Type
Mass (kg)
Outer
defined kg)
prev (m)
(T) Twin
265/70
No
(T) Tandem
(A) Air Bag
1.88
9000.00
6.63
Tyred Axle
R19.5
(T) Twin
265/70
No
(T) Tandem
(A) Air Bag
1.88
9000.00
1.31
Tyred Axle
R19.5
(T) Twin
265/70
No
(Tri) Tri-axle
(A) Air Bag
1.88
9000.00
3.18
Tyred Axle
R19.5
(T) Twin
265/70
No
(Tri) Tri-axle
(A) Air Bag
1.88
9000.00
1.26
Tyred Axle
R19.5
(T) Twin
265/70
No
(Tri) Tri-axle
(A) Air Bag
1.88
9000.00
1.27
Tyred Axle
R19.5
